详细信息| 询价留言NAT 8252 – Industrial Pressure Switch
The industrial pressure switch NAT 8252 is available with 1 or 2 switching outputs and features an exceptionally long-term stable thin-film-on-steel sensor cell with triple (optionally 5-fold) overpressure safety. The robust design and the wide temperature range from -40°C to +125°C qualify the NAT 8252 as the ideal solution for a wide range of demanding pressure switch applications
Technical Data
Applications Machine tools, Hydraulics, HVAC, Refrigeration, Process technology, Water treatment Category Electronic pressure switches Accuracy @ 25°C typ. ± 0.5 % FS typ. Dielectric strength 50 VAC, 50 Hz Measuring principle Thin-film-on-steel Vibration 15 g RMS (20...2000 Hz) (EN60068-2-64)
25 g sin (80...2000 Hz), 1 oct./min, (1x @ 25°C) (EN60068-2-6)NLH @ 25°C (BSL) typ. ± 0.2 % FS typ. Pressure connections G1/4" m, G1/4" m (Manometer);
1/4"NPT m, 1/8"NPT m;
7/16"-20UNF f, SAE J512;
7/16"-20UNF m, SAE4 (J1926);
7/16"-20UNF m, DIN3866;
9/16"-18UNF m, SAE6 (J1926);
R1/4" m, DIN3858;
R1/4" m, DIN2999;
R1/8" m, DIN3858;
M10x1Media temperature –40°C ... +125°C Shock 50 g / 11 ms
100 g / 6 ms Male electrical plug M12x1 (EN60068-2-27) 2)Electrical connections M12x1; Cable IP67 (IP68) Long term stability 1 year typ. < ± 0.1 % FS typ. Ambient temperature –40°C ... +125°C
(Cable PVC 22: -5°C ... +60°C)
(Cable PUR 24: -40°C ... +70°C)Protection IP65, IP67, IP68 Output signal Switching output:
1 or 2 PNP transistorsTEB typ. @ -25 ... +85°C ± 1.75 % FS typ. Measuring range 0 ... 2.5 to 0 ... 600 bar
0 ... 30 to 0 ... 7500 psi -
